Copyright © 2010, Juniper Networks, Inc.
From , connect the other end of the cable into the port labeled
TXP-CIP-0
the on the T1600 router.
LCC-CB-0
From TXP-CIP-0 , connect the other end of the cable to the port labeled
the on the T1600 router.
LCC-CB-1
NOTE: The RJ-45 ports labeled
reserved for future use.
Arrange the cable appropriately. You can route the control plane cables into the
6.
optional T1600 rear cable management system (see Figure 94 on page 234). Loosen
the soft band strap for each control plane cable, route the cable through the soft band
strap, and fasten it. Route the cables upward toward the top of the chassis and through
the soft band straps located to the left, and fasten them.

Figure 93: Connecting a TX Matrix Plus Control Plane

Chapter 18: Integrating an Offline T1600 Router into a Routing Matrix
through
SFC1
NC
C
NO
NC
C
NO
SP EE D:
YE L=1
0/1 00
GR N= 100
0
on
SFC0
SFC0 on
on the TXP-CIP are
SFC3
233
