TX Matrix Plus Router Hardware Guide

Installing the Open-Frame Rack Mounting Shelf

124
Table 34: Mounting Hole Locations for Installing a TX Matrix Plus Chassis
in an Open-Frame Rack (continued)
Hole Distance Above U Division
24 13.75 in. (34.9 cm)
18 10.25 in. (26.0 cm)
12 6.75 in. (17.1 cm)
Before mounting the chassis in an open-frame rack, you must first install the open-frame
rack mounting shelf.
To install the open-frame rack mounting shelf, (see Figure 49 on page 125):
On the rear of each rack rail, partially insert a mounting screw into the highest hole
1.
specified in Table 33 on page 122 for the open-frame rack mounting shelf.
Install the open-frame rack mounting shelf on the rack. Hang the shelf over the
2.
mounting screws using the keyhole slots located near the top of the shelf flanges.
Partially insert screws into the open holes in the flanges of the open-frame rack
3.
mounting shelf.
Tighten all the screws completely.
4.
Chassis
7.86 U
X
5.86 U
X
3.86 U
X
