TX Matrix Plus Router Hardware Guide

Upgrading the SIBs in the T1600 Router

Before you connect an offline T1600 router to the TX Matrix Plus router, you must replace

the SIBs with TXP-T1600 SIBs.

Attach an electrostatic discharge (ESD) grounding strap to your bare wrist, and connect

the strap to one of the ESD points on the chassis.

Replace each SIB with a TXP-T1600 SIB (Figure 92 on page 229). Use the standard

replacement procedure described in the T1600 Core Router Hardware Guide.

NOTE: Ensure that the ejector handle tabs are properly mated inside their

corresponding chassis slots before you tighten the captive screws on the

ejector handles. You might have to close and open the handles a few times

before the tabs catch the slots.
