TX Matrix Plus Router Hardware Guide
Tools and Parts Required for Upgrading and Integrating an Operational T1600 Router
202
Prepare to upgrade the SIBs.
11.
See "Upgrading and Connecting the Switching Planes in an Operational T1600 Router"
on page 211.
Connect and integrate one switching plane.
12.
See "Upgrading and Connecting the Switching Planes in an Operational T1600 Router"
on page 211.
NOTE: During the upgrade and connection of the switching planes, the
T1600 router might experience some packet loss, depending on the
operational environment. For more information, contact your customer
support representative.
Connect and integrate each remaining switching plane one at a time.
13.
See "Upgrading and Connecting the Switching Planes in an Operational T1600 Router"
on page 211.
Connect the control planes between an operational T1600 router and TX Matrix Plus
14.

router.

See "Connecting the Control Planes in an Operational T1600 Router" on page 219.
Set the switch on each LCC-CB faceplate to
M/S
15.
See "Setting the M/S Configuration Switches on the T1600 LCC-CBs" on page 221.
Transfer the T1600 configuration file to the routing matrix.
16.
See "Transferring the T1600 Router Configuration to the TX Matrix Plus Router in an
Operational T1600 Router" on page 221.
Transfer control of the T1600 router to the TX Matrix Plus router.
17.
See "Transferring Control of the T1600 Router to the TX Matrix Plus Router" on page 222.
NOTE: Additional T1600 routers you integrate must be offline. Follow the
procedures described in "Overview of Upgrading an Offline T1600 Router
Before Integrating it into a Routing Matrix" on page 223 and "Overview of
Integrating an Offline T1600 Router into a Routing Matrix" on page 231.
To connect the TX Matrix Plus router to an operational T1600 router, you need the
following tools and parts:
Phillips (+) screwdriver, number 2
Dust-free resealable plastic bags for temporary storage of fiber-optic array port dust
covers
.
M
