On the front rack rails, insert cage nuts in the holes specified for mounting the chassis.
3.
Install the cage nuts in the front of the front rail. (see Table 32 on page 118)
Table 31: Mounting Hole Locations for Installing the TX Matrix Plus
Four-Post Mounting Shelf and Rear-Support Bracket
Hole Distance Above U Division
6 3.25 in. (8.3 cm)
5 2.63 in. (6.7 cm)
4 2.00 in. (5.1 cm)
3 1.50 in. (3.8 cm)
2 0.88 in. (2.2 cm)
1 0.25 in. (0.6 cm)
The holes in the front-mounting flanges are spaced at 2 U (3.5 in. or 8.9 cm).
Table 32: Mounting Hole Locations for Installing a TX Matrix Plus Chassis
in a Four-Post Rack
Hole Distance Above U Division
87 50.50 in. (128.3 cm)
81 47.00 in. (119.4 cm)
75 43.50 in. (110.5 cm)
69 40.00 in. (101.6 cm)
63 36.5 in. (92.7 cm)
57 33.00 in. (88.8 cm)
51 29.50 in. (74.9 cm)
45 24.26 in. (61.6 cm)
39 22.51 in. (57.2 cm)
33 19.01 in. (48.3 cm)
27 15.51 in. (39.4 cm)
21 12.00 in. (30.5 cm)
Four-Post Rack
Mounting Shelf
1.86 U
X
1.5 U
X
1.14 U
X
0.86 U
X
0.50 U
X
0.14 U
X
28.86 U
26.86 U
24.86 U
22.86 U
20.86 U
18.86 U
16.86 U
14.86 U
12.86 U
10.86 U
8.86 U
6.86 U
