Tools and Parts Required to Upgrade the T1600 Router Hardware Components
Upgrading an Offline T1600 Router Before Integrating it into a Routing Matrix

Upgrading the Routing Engines in the T1600 Router

Upgrading the Junos OS on a T1600 Router

Copyright © 2010, Juniper Networks, Inc.
Chapter 17: Upgrading an Offline T1600 Router Before Integrating It into a Routing Matrix
To convert a T1600 router, you need the following tools and parts:
Phillips (+) screwdriver, number 2
Electrostatic discharge (ESD) grounding wrist strap
Upgrading the Routing Engines in the T1600 Router on page 225
1.
2. Upgrading the Junos OS on a T1600 Router on page 225
Powering Off the T1600 Router on page 226
3.
Replacing the T1600 Power Supplies on page 226
4.
Upgrading the T1600 Rear Fan Tray on page 227
5.
Setting the Chassis ID on the T1600 Router on page 227
6.
Upgrading the T-CBs in the T1600 Router with LCC-CBs on page 227
7.
8. Upgrading the SIBs in the T1600 Router on page 228
To upgrade each Routing Engine:
Attach an electrostatic discharge (ESD) grounding strap to your bare wrist, and connect
1.
the strap to one of the ESD points on the chassis.
Follow the standard replacement procedure described in the T1600 Core Router
2.
Hardware Guide.
You must upgrade the router to Junos OS Release 9.6R2 or later for offline integration
of the T1600 router.
To upgrade the software, you use CLI commands to copy a set of software images over
the network to memory storage on the Routing Engine. The Junos OS set consists of
several images provided in individual packages or as a bundle. You normally upgrade all
packages simultaneously.
To upgrade the software:
Upgrade the Junos OS running on the T1600 router.
1.
For information about installing and upgrading Junos OS, see the Routing Matrix with
a TX Matrix Plus Router Feature Guide and Junos OS Installation and Upgrade Guide.
After you are satisfied that the new packages are successfully installed and running,
2.
issue the request system snapshot
For more information, see the Junos OS System Basics Configuration Guide.
command to back up the new software.
225
