TX Matrix Plus Router Hardware Guide

Table 56: Effect of Switching a TX Matrix Plus or T1600 Routing Engine

Configuration
The
on-loss-of-keepalives
statement is included at the
chassis redundancy failure]
hierarchy level
The
on-loss-of-keepalives
statement is not included at the
[edit chassis redundancy failure]
hierarchy level
Related
Documentation

Tools and Parts Required to Replace TX Matrix Plus Hardware Components

326
Effect of a Change in Mastership
You or a host subsystem initiates a change in mastership to the backup Routing Engine in
the TX Matrix Plus router—The master Routing Engines in the T1600 routers detect a software
[edit
release mismatch with the new master Routing Engine in the TX Matrix Plus router and
switch mastership to their backup Routing Engines.
You attempt to initiate a change in mastership to a backup Routing Engine in a T1600
router—The new master Routing Engine in the T1600 router detects a software release
mismatch with the master Routing Engine in the TX Matrix Plus router and relinquishes
mastership to the original master Routing Engine. Routing Engine mastership in the TX Matrix
Plus router does not switch in this case.
A host subsystem initiates a change in mastership to a backup Routing Engine in a T1600
router because the master Routing Engine has failed—The T1600 router is logically
disconnected from the TX Matrix Plus router.
You initiate a change in mastership to the backup Routing Engine in the TX Matrix Plus
router—All T1600 routers are logically disconnected from the TX Matrix Plus router.
You initiate a change in mastership to a backup Routing Engine in a T1600 router—The
T1600 router is logically disconnected from the TX Matrix Plus router. To reconnect the
T1600 router, switch mastership of the new master Routing Engine in the T1600 router back
to the original master Routing Engine.
TX Matrix Plus Routing Engine Description on page 25
Junos OS Releases in the Routing Matrix on page 71
Taking the Host Subsystem Offline on page 354
To replace hardware components, you need the tools and parts listed in Table 57 on
page 326.

Table 57: Tools and Parts Required for Component Replacement

Components
All
Power cables
Power supply
TXP-CB
Routing Engine
Tool or part
Electrostatic discharge (ESD) grounding wrist
strap
7/16-in. (11 mm) nut driver or socket wrench
Phillips (+) screwdriver, number 2
Electrostatic bag or antistatic mat
Electrostatic bag or antistatic mat
