Figure 19: TX Matrix Plus TXP-CIP

ONLINE/OFFLINE
button
Status LEDs
LCC Control
plane ports
SFC Control
plane ports
Alarm relay
connectors
SP EE D:
Each TXP-CIP houses:
Ports for connections to the LCC control plane, SFC control plane, and other devices.
NOTE: The SFC control plane ports are reserved for future use.
Alarm relay contacts
Three LEDs— ACTIVE , OK
and port LEDs for the
ACT SPEED
Port LEDs for the reserved ports
and port LEDs for the
ACT LINK
The TXP-CIPs are hot-removable and hot-insertable.

TXP-CIP Ports

LCC Control Plane Ports
Control plane connections to the T1600 routers in the routing matrix are provided by
sixteen 10/100/1000 Base-T copper RJ-45 LCC control plane ports labeled
PLANE 0 through 15 on the TXP-CIP. UTP Category 5E Ethernet cables connect the
ports in
CTRL PLANE TXP-CIP-0
in each T1600 router. For more information about connecting TXP-CIPs to LCC-CBs, see
Chapter 2: TX Matrix Plus Hardware Component Overview
NC
C
NO
NC
C
NO
YE L=1
0/1 00
GR N= 100
0
, FAIL — that indicate the status of the TXP-CIP.
LCC CTRL PLANE
16 and 17
ports
SFC CTRL PLANE
and to the LCC-CBs
TXP-CIP-1
ports through
0 15
through
XGE0 XGE4
LCC CTRL
and
LCC-CB-0 LCC-CB-1
LCC
