Figure 140: ESD Point on Front of the TX Matrix Plus Router

Craft interface panel
ESD
point
TXP-F2
SIBs
Air
intake
(2 air
filters)
TXP-F2
SIBs
ESD
point
Air
intake
(air filter)
Appendix A: TX Matrix Plus Safety and Regulatory Compliance Information
Center-mounting bracket
Fan tray 0
RE 0
RE 1
CB 0
CB 1
CIP 0
CIP 1
Front cable
manager
Fan tray 1
393
