CHAPTER 17
Upgrading an Offline T1600 Router Before
Integrating It into a Routing Matrix
Overview of Upgrading an Offline T1600 Router Before Integrating it into a Routing

Matrix

Copyright © 2010, Juniper Networks, Inc.
Overview of Upgrading an Offline T1600 Router Before Integrating it into a Routing
Matrix on page 223

Tools and Parts Required to Upgrade the T1600 Router Hardware

Components on page 225
Upgrading an Offline T1600 Router Before Integrating it into a Routing Matrix on page 225
Registering Your T1600 Upgrade on page 229
The routing matrix includes up to four T1600 routers connected to a TX Matrix Plus router.
If the T1600 router is operational (passing traffic), use the procedures described in
"Overview of Upgrading and Integrating an Operational T1600 Router" on page 201.
NOTE: Do not power on the T1600 router until instructed to do so.
For information about installing a new T1600 router, see the T1600 Core Router Hardware
Guide.
You must proceed through the upgrade process in the following order:
Order the hardware. The hardware upgrade kit includes two LCC-CBs and five
1.
TXP-T1600 SIBs. The Routing Engines must be ordered separately. The rear fan tray
and power supplies, if needed, can also be ordered separately.
See the T1600 Core Router Hardware Guide.
Prepare the installation site for the T1600 router.
2.
See "Overview of Preparing the Site for a TX Matrix Plus Router" on page 103 and the
T1600 Core Router Hardware Guide.
Review all safety guidelines and warnings for both the TX Matrix Plus router and T1600
3.
router.
223
