TX Matrix Plus Router Hardware Guide
Related
Documentation
220
Plug the other end of the cable into the port labeled
5.
T1600 router. Arrange the cable appropriately.
Verify that the LINK LED on both LCC-CBs in the T1600 router are lit green.
6.

Figure 89: Connecting a TX Matrix Plus Control Plane

Figure 90: LCC-CB LEDs on the T1600 Router

Control Plane Connections from the TX Matrix Plus Router to the T1600 Routers on
page 58
Overview of Preparing to Upgrade and Integrate an Operational T1600 Router on
page 199
Overview of Upgrading and Integrating an Operational T1600 Router on page 201
SFC0
NC
C
NO
NC
C
NO
SP EE D:
YE L=1
0/1 00
GR N= 100
0
Link
Activity
LED
LED
Copyright © 2010, Juniper Networks, Inc.
on the on the
LCC-CB-1
