TX Matrix Plus Router Hardware Guide
RJ-45 Connector Pinouts for the TX Matrix Plus Routing Engine AUXILIARY and
CONSOLE Ports
Related
Documentation
446
The ports on the TXP-CB labeled
accept RS-232 (EIA-232) cable. The
laptop, modem, or other auxiliary unit, and the
management console. The ports are configured as data terminal equipment (DTE). For
more information, see "Routing Engine Ports on the TXP-CB" on page 23. Table 68 on
page 446 describes the DB-9 connector pinouts.

Table 68: RJ-45 Connector Pinouts for the TX Matrix Plus AUXILIARY and

CONSOLE Ports
Pin Signal
1 DCD
2 RxD
3 TxD
4 DTR
5 Ground
6 DSR
7 RTS
8 CTS
9 RING
TX Matrix Plus TXP-CB Overview on page 21
Routing Engine Ports on the TXP-CB on page 23.
Connecting the TX Matrix Plus Router to a Management Console or Auxiliary Device
on page 160
and
AUXILIARY CONSOLE
port connects the Routing Engine to a
AUXILIARY
CONSOLE port connects it to a
Direction Description
<– Carrier Detect
<– Receive Data
–> Transmit Data
–> Data Terminal Ready
— Signal Ground
<– Data Set Ready
–> Request To Send
<– Clear To Send
<– Ring Indicator
Copyright © 2010, Juniper Networks, Inc.
are RJ-45 receptacles that
