TX Matrix Plus Rear Cable Management System

Copyright © 2010, Juniper Networks, Inc.
Fiber-Optic Array Cable Connections and Considerations on page 109
Routing Matrix with a TX Matrix Plus Router Hardware Configuration Overview on
page 104
TX Matrix Plus Routing Engine Interface Cable Specifications on page 443
RJ-45 Connector Pinouts for the TX Matrix Plus Routing Engine ETHERNET Port on
page 445
RJ-45 Connector Pinouts for the TX Matrix Plus Routing Engine AUXILIARY and
CONSOLE Ports on page 446
The TX Matrix plus rear cable management system installs in the rear and top of the
TX Matrix Plus chassis. It organizes, supports, and provides strain relief for the fiber-optic
array cables connected to the TXP-F13 SIBs. The fiber-optic array cables (see Figure 28
on page 52) are routed to the sides of the TX Matrix Plus router, and then toward the top
of the chassis, where you can route the cables to the T1600 routers. The cable
management system adds 9 in. (22.86 cm) to the depth of the chassis.
NOTE: We recommend that you use the TX Matrix plus rear cable
management system to maintain the fiber-optic array cable bend radius.
The cable management system consists of three shelves connected to four cable
management arms. Cables connected to the odd side of theTXP-F13 SIBs in slots 0
through 7 are routed to the upper right cable management arm, and the cables connected
to the even side are routed to the upper left cable management arm. cables connected
to the odd side of the TXP-F13 SIBs in slots 8 through 15 are routed to the lower right
cable management arm, and the cables connected to the even side are routed to the
lower left cable management arm.
Figure 26 on page 50 shows the TX Matrix Plus cable management system.
