TX Matrix Plus Switch Interface Boards Overview

TX Matrix Plus Switch Interface Boards Description

Related
Documentation

TX Matrix Plus TXP-F13 SIB Overview

Copyright © 2010, Juniper Networks, Inc.
TX Matrix Plus Switch Interface Boards Description on page 13
TX Matrix Plus TXP-F13 SIB Overview on page 13
TX Matrix Plus TXP-F13 SIB LEDs on page 15
TX Matrix Plus TXP-F2S SIB Overview on page 17
TX Matrix Plus TXP-F2S SIB LEDs on page 19
The TX Matrix Plus Router contains TXP-F13 SIBs and TXP-F2S SIBs that connect together
through the midplane to create the switch fabric for the TX Matrix Plus router.
TX Matrix Plus TXP-F13 SIB Overview on page 13
TX Matrix Plus TXP-F2S SIB Overview on page 17
Routing Matrix with a TX Matrix Plus Router Switch Fabric and Switching Plane
Architecture on page 60
TXP-F13 SIB Description on page 13
TXP-F13 SIB Slots on page 14

TXP-F13 SIB Description

TXP-F13 SIBs are hot-removable and hot-insertable (see Figure 5 on page 13).

Figure 5: TXP-F13 SIB

Each TXP-F13 SIB consists of the following components:
Switch Fabric ASICs.
High-speed electrical links through the midplane to the TXP-F2S SIBs on the same
switching plane.
Chapter 2: TX Matrix Plus Hardware Component Overview
13
