Juniper TX MATRIX PLUS Hardware Manual page 103

Table 22: Fiber-Optic Array Cable Connections to Four T1600 Routers (continued)
TX Matrix Plus Router
TXP-SIB13 TXP-SIB13
SIB Slot Side
Slot 12 Even
Slot 12 Even
Slot 12 Odd
Slot 12 Odd
Slot 12 Odd
Slot 12 Odd
Related
Documentation
Copyright © 2010, Juniper Networks, Inc.
Chapter 3: Routing Matrix with a TX Matrix Plus Router System Architecture Overview
Port Cable Labels
C
SFC: 0-12-0-C >
2-4-C
D
SFC: 0-12-0-D >
2-4-D
A SFC: 0-12-1-A >
3-4-A
B SFC: 0-12-1-B >
3-4-B
C SFC: 0-12-1-C >
3-4-C
D SFC: 0-12-1-D >
3-4-D
TX Matrix Plus Router Description on page 3
Routing Matrix with a TX Matrix Plus Router System Architecture on page 55
Routing Matrix with a TX Matrix Plus Router Switch Fabric and Switching Plane
Architecture on page 60
TX Matrix Plus TXP-F13 SIB Overview on page 13
TX Matrix Plus TXP-F2S SIB Overview on page 17
T1600 Router
T1600
router
LCC 2
LCC: 2-4-C ->
0-12-0-C
LCC 2
LCC: 2-4-D ->
0-12-0-D
LCC: 3-4-A -> LCC 3
0-12-1-A
LCC: 3-4-B -> LCC 3
0-12-1-B
LCC: 3-4-C -> LCC 3
0-12-1-C
LCC: 3-4-D -> LCC 3
0-12-1-D
TXP-T1600
SIB Slot Port
Slot 4 C
Slot 4 D
Slot 4 A
Slot 4 B
Slot 4 C
Slot 4 D
69
