TX Matrix Plus Cooling System Overview

TX Matrix Plus Power System Description on page 41

TX Matrix Plus Seven-Input 420-A Power Supplies Overview on page 41

Power Supply LEDs on the TX Matrix Plus Craft Interface on page 35

Troubleshooting the TX Matrix Plus Power System on page 290

Cooling System Description on page 45

Fan Trays on page 46

Air Filters on page 47

The cooling system components work together to keep all TX Matrix Plus components

within the acceptable temperature range (see Figure 24 on page 45).

To function properly, the entire cooling system requires an unobstructed airflow and

proper clearance around the site. Figure 24 on page 45 shows the airflow through the

Airflow (front boards)

Airflow (back boards)

The cooling system consists of the following components:

Two front fan trays

Three front air filters

Four rear fan trays

Chapter 2: TX Matrix Plus Hardware Component Overview

Airflow (front boards)
