Rolling Back the Integration on the T1600 Router

Preparing to Roll Back the Integration

318

Figure 102: Fiber-Optic Array Loopback Connector and Loopback Adapter

Loopback adapter
TX Matrix Plus Preventing Electrostatic Discharge Damage on page 392
Cleaning Fiber-Optic Array Components with the Dry Cloth Cleaning Tool on page 271.
To return the T1600 router to its original state as a standalone system after you have
transferred control to the TX Matrix Plus router, you can roll back the integration. During
the rollback, traffic passing through the router will be interrupted. This procedure uses
as an example.
LCC0
1. Preparing to Roll Back the Integration on page 318
Removing the Control Plane Connections on page 319
2.
Removing the Switching Planes on page 319
3.
Returning to the Original T1600 Configuration on page 320
4.
Attach an electrostatic discharge (ESD) grounding strap to your bare wrist, and connect
1.
the strap to one of the ESD points on the chassis.
Take each TXP-T1600 SIB offline by using one of the following methods:
2.
Press and hold the
ONLINE/OFFLINE
the LED is not lit.
OK
On an external management device connected to the console or auxiliary port of
the TXP-CB, issue the
user@host> request chassis sib lcc 0 slot 0 offline
If the statement is included at the
3. online-expected
level, delete it:
user@host# delete chassis lcc 0 online-expected
Issue the
commit synchronize
4.
errors:
Loopback connector
button on the TXP-T1600 SIB faceplate until
command:
request chassis sib offline
[edit chassis lcc number]
command and ensure that there are no synchronization
hierarchy
