Installing the TX Matrix Plus Mounting
Hardware

Overview of Installing TX Matrix Plus Mounting Hardware

Related
Documentation

Installing the TX Matrix Plus Mounting Hardware for a Four-Post Rack

Installing Cage Nuts, If Needed

Copyright © 2010, Juniper Networks, Inc.
Overview of Installing TX Matrix Plus Mounting Hardware on page 117
Installing the TX Matrix Plus Mounting Hardware for a Four-Post Rack on page 117
Installing the TX Matrix Plus Mounting Hardware for an Open-Frame Rack on page 122
You can install the TX Matrix Plus router in either an open-frame rack or four-post rack.
Use the procedure appropriate for your rack.
Rack Requirements for a TX Matrix Plus Router on page 106
Installing the TX Matrix Plus Mounting Hardware for a Four-Post Rack on page 117
Installing the TX Matrix Plus Mounting Hardware for an Open-Frame Rack on page 122
Installing Cage Nuts, If Needed on page 117
1.
Installing the Four-Post Mounting Shelf and Rear Support Bracket on page 119
2.
Removing the Center-Mounting Brackets on page 120
3.
Insert cage nuts, if needed, into the holes listed in Table 31 on page 118 and Table 32 on
page 118 (an indicates a mounting hole location). The hole distances are relative to the
X
standard U division on the rack that is aligned with the bottom of the mounting shelf and
rear support bracket.
To install cage nuts in a four-post rack:
On the rear rack rails, insert cage nuts in the holes specified for the rear support bracket.
1.
Install the cage nuts in the rear of the rear rail (see Table 31 on page 118).
On the front rack rails, insert cage nuts in the holes specified for the four-post mounting
2.
shelf. Install the cage nuts in the front of the front rail. (see Table 31 on page 118)
