T1600 Hardware Component Overview

TXP-T1600 SIBs on page 93

RE-C1800 Routing Engines on page 95

LCC-CBs on page 96

The TXP-T1600 SIBs connect to the TX Matrix Plus router. Each T1600 router contains

five SIB slots located at the center rear of the chassis. Each TXP-T1600 SIB contains

four fiber-optic array ports labeled

the TX Matrix Plus router (see Figure 39 on page 94).

that connect it to the TXP-F13 SIBs on
