Removing the TXP-F2S SIBs

Copyright © 2010, Juniper Networks, Inc.
Up to twenty TXP-SIBs are installed in the front of the TX Matrix Plus router. Each TXP-F2S
SIB weighs approximately 3.4 lb (1.5 kg).
The TXP-F2S SIBs are located in the front of the chassis in the following slots:
, , ,
SIB0/0 SIB0/2 SIB0/4
, , ,
SIB1/0 SIB1/2 SIB1/4 SIB1/6
SIB2/0 , SIB2/2 , SIB2/4 , SIB2/6
, , ,
SIB3/0 SIB3/2 SIB3/4
SIB4/0 , SIB4/2 , SIB4/4 ,
To remove the TXP-F2S SIBs (see Figure 54 on page 133):
Place an electrostatic bag or antistatic mat on a flat, stable surface.
1.
Attach an electrostatic discharge (ESD) grounding strap to your bare wrist, and connect
2.
the strap to an approved site ESD grounding point. See the instructions for your site.
Release the latch on the ejector handle of the TXP-F2S SIB faceplate.
3.
Flip the ejector handles outward to unseat the TXP-F2S SIB.
4.
Grasp the ejector handle, pull firmly, and slide the TXP-F2S SIB about halfway out of
5.
the chassis.
Place one hand underneath the TXP-F2S SIB to support it, and slide it completely out
6.
of the chassis. Place it on the antistatic mat.
CAUTION: When the TX-SIB is out of the chassis, do not hold it by its
ejector handles or edge connectors.
CAUTION: Do not stack hardware components on one another after you
remove them. Place each component on an antistatic mat resting on a
stable, flat surface.
Repeat the procedure for each of the remaining TXP-F2S SIBs.
7.
Chapter 11: Installing the TX Matrix Plus Router Using a Mechanical Lift
SIB0/6
SIB3/6
SIB4/6
