The midplane performs the following major functions:
Power distribution—The TX Matrix power supplies are connected to the midplane,
which distributes power to all the TX Matrix components.
Signal connectivity—The midplane provides signal connectivity between all TX Matrix
components for monitoring and controlling the system.
Redundancy connectivity—The midplane provides redundant paths for all critical
connections.

Figure 4: TX Matrix Plus Router Midplane

Midplane
TX Matrix Plus Router Description on page 3
TX Matrix Plus Switch-Fabric Chassis Description on page 8
TX Matrix Plus Component Redundancy on page 7
