Labeling the Fiber-Optic Array Cables

182
Each cable has two labels that contain information about the connections between the
switch-fabric chassis (SFC) and the line-card chassis (LCC). For the SFC, each label
indicates the SFC chassis ID number (always 0 for the A4 configuration), TXP-SIB slot
number, even (0) or odd (1) side of the TXP-F13, and the port on the TXP-F13. For the
LCC, each label indicates the LCC chassis ID number, TXP-T1600 SIB slot, and the port.
For example, use the labels marked
TXP-F13 SIB in slot 0 and
T1600 router to identify a connection between the TX Matrix Plus router (SFC)
LCC0
and T1600 router (LCC).
Locate the supplied blank label sheets in the accessory box.
1.
See Table 38 on page 182 to identify which TXP-F13 SIB slots are supported for your
2.
hardware configuration and locate the labels for those slots.
Print the labels on the blank label sheets. See the TX Matrix Plus Fiber-Optic Array
3.
Cable Label Guide.
Attach a label to each end of the fiber-optic array cable to help you identify the
4.
corresponding TXP-F13 SIB and TXP-T1600 SIB.

Table 38: TXP-13 Slots and Correcsponding LCCs Supported

Slot
0
1
2
3
4
5
6
7
8
9
10
11
12
SFC: 0-0-0-A > 0-0-A
port A on the LCC-SIB in slot 0 in the
LCC: 0-0-A -> 0-0-0-A
LCCs Supported
LCC0 and LCC1
LCC2 and LCC3
–
LCC0 and LCC1
LCC2 and LCC3
–
LCC0 and LCC1
LCC2 and LCC3
LCC0 and LCC1
LCC2 and LCC3
–
LCC0 and LCC1
LCC2 and LCC3
port A on the even side of the
