TX Matrix Plus Router Hardware Guide

Powering On the T1600 Router

Related
Documentation
Displaying the Assigned MAC Addresses for the PIC Interfaces in the Routing Matrix
Related
Documentation
242
After you have connected the control and switching planes between the T1600 router
and the TX Matrix Plus router, power on the T1600 router and monitor the boot process.
Attach an electrostatic discharge (ESD) grounding strap to your bare wrist, and connect
1.
the strap to one of the ESD points on the chassis.
Switch the circuit breakers on one of the power supplies to the on position (
2.
If the system is completely powered off when you power on the power supply, the
Routing Engine boots as the power supply completes its startup sequence. If the
Routing Engine finishes booting and you need to power off the system again, see the
T1600 Core Router Hardware Guide.
Observe the LEDs on the power supply faceplate. If the power supply is correctly
3.
installed and is functioning properly, the
steadily.
NOTE: After a power supply is powered on, it can take up to 60 seconds
for status indicators—such as the output status LEDs on the power supply,
the command display output, and messages on the LCD display on the
craft interface—to indicate that the power supply is functioning normally.
Ignore error indicators that appear during the first 60 seconds. After
powering on a power supply, wait at least 60 seconds before turning it
off.
Repeat the procedure for the remaining power supply.
4.
On an external management device connected to the console or auxiliary port of the
5.
CIP in the T1600 router, monitor the startup process to verify that the system has
booted properly.
Connecting an Offline T1600 Router to the TX Matrix Plus Router on page 232
TX Matrix Plus Preventing Electrostatic Discharge Damage on page 392
After you integrate a T1600 router into a routing matrix, the PIC media access control
(MAC) addresses for the T1600 router are derived from a pool of MAC addresses
maintained by the TX Matrix Plus router. The PIC MAC addresses used in the formerly
standalone T1600 router are changed.
To display the newly assigned MAC address for an interface on a PIC in a T1600 router
integrated into the routing matrix, issue the
TX Matrix Plus CLI Overview on page 72
TX Matrix Plus Interface Names Overview on page 75
PEM OK LED blinks momentarily, then lights
show interfaces interface-name
Copyright © 2010, Juniper Networks, Inc.
| ).
command.
