CDM-750 Advanced High-Speed Trunking Modem
Front Panel Operation

5.2.2 Select: (Main) Menu

Select: Configuration
Info
The Select: (main) menu provides user access to all modem configuration, monitor and control
menu branches.
The table that follows identifies the functional description/overview for each menu branch. Refer
to the chapter section for detailed information about the operations provided therein.
Select:
Configuration
Test
Monitor
Info
Store/Ld
Utility
ODU
FAST
Use the ◄ ► arrow keys to select from the menu branch choices shown, and then press ENTER.
Store/Ld Utility
Sect. Menu Branch Description
5.2.2.1 Used to fully configure the modem.
Used to configure the modem into one of several Test modes, and
5.2.2.2
configures/monitors the BER Tester.
Used to monitor the current status of the modem and view the log of stored events
5.2.2.3
for the modem.
(Information) Used to view information on the modem, without having to go into the
5.2.2.4
Configuration screens.
5.2.2.5 (Store/Load) Used to store and retrieve up to 10 different modem configurations.
Used to perform miscellaneous functions, such as setting the Real-Time Clock,
5.2.2.6
adjusting the display brightness, etc.
MENU ITEM CURRENTLY NOT AVAILABLE.
N/A
(Fully Accessible System Topology) Used to verify installed options and configure
5.2.2.7 different options, e.g., extended data rates, interfaces, etc. Contact Comtech EF
Data Customer Support for details.
Test Monitor
ODU FAST
