CDM-625 Advanced Satellite Modem
Front Panel Operation
5.3

SELECT: (Main) Menu

Select: Configuration
Info
◄ ►
Use the arrow keys to select from the choices shown, then press ENTER. The following
table identifies the menu branch, its content section in this chapter, and the functional description
of each branch:
Menu Branch
Configuration
Test
Monitor
Info
Store/Ld
Utility
ODU
FAST
IMPORTANT
Store/Ld Utility
Sect Description
Permits the user to fully configure the modem.
5.4
Permits the user to configure the modem into one of several Test modes.
5.5
Permits the user to monitor the current status of the modem and view the
5.6
log of stored events for the modem.
(Information) Permits the user to view information on the modem, without
5.7
having to go into the Configuration screens.
(Store/Load) Permits the user to store and retrieve up to 10 different
5.8
modem configurations.
Permits the user to perform miscellaneous functions, such as setting the
5.9
Real-Time Clock, adjusting the display brightness, etc.
(Outdoor Unit) Permits the user to monitor and control a Comtech EF
5.10
Data RF Transceiver, if connected.
(Fully Accessible System Topology) Permits the user to configure
different options, for extended data rates, interfaces, etc. Contact the
5.11
factory for details.
The actual choices displayed in the submenus may vary according to which
FAST options have been enabled. Where a FAST option affects a menu, this
is shown in the descriptive text.
MN-0000036 (Ref MN/CDM625.IOM)
Test Monitor
ODU FAST
5–6
Revision 1
