CDM-710 Broadcast Satellite Modem
Front Panel Operation
5.3

SELECT: (Main) Menu

SELECT: Config
Test Info Save/Load Util
Move the cursor to the desired choice using the
following table describes the function of each menu branch (along with the section in this chapter
that provides information on that branch and its accompanying submenus):
SELECTION
Config
Monitor 5.3.2
Test 5.3.3
Info 5.3.4
Save/Load 5.3.5
Util 5.3.6
Monitor
Sect MENU BRANCH DESCRIPTION
(Configuration) Provides the user selections for the desired Interface, Transmit, and
5.3.1
Receive operations.
Permits the user to monitor the alarm status of the unit, to view the log of stored events, and
to display the Receive Parameters screen.
Permits the user to configure the modem into one of several Test modes; e.g., CW and
Loopback.
(Information) Provides a summary/display of the Interface, Transmit, Receive, and M&C
configurations.
Permits the user to save and retrieve up to 10 different modem configurations.
(Utility) Permits the user to perform miscellaneous functions, such as setting the Real-Time
Clock, adjusting the display brightness, etc.
arrow keys, then press
5–6
Revision 11
MN/CDM710.IOM
. The
ENTER
