lbu
Load Byte Unsigned
lbu rD, rA, rB
lbur rD, rA, rB
lbuea rD, rA, rB
1 1 0 0 0 0
0 6
Description
Loads a byte (8 bits) from the memory location that results from adding the contents of registers rA
and rB. The data is placed in the least significant byte of register rD and the other three bytes in rD
are cleared.
If the R bit is set, a byte reversed memory location is used, loading data with the opposite endianness
of the endianness defined by the E bit (if virtual protected mode is enabled).
If the EA bit is set, an extended address is used, formed by concatenating rA and rB instead of adding
them.
A data TLB miss exception occurs if virtual protected mode is enabled, and a valid translation entry
corresponding to the address is not found in the TLB.
A data storage exception occurs if access is prevented by a no-access-allowed zone protection. This
only applies to accesses with user mode and virtual protected mode enabled.
Pseudocode
if EA = 1 then
← (
Addr rA) & (rB)
else
← (
Addr rA) + (rB)
if TLB_Miss(Addr) and MSR[VM] = 1 then
←
ESR[EC]
MSR[UMS]
else if Access_Protected(Addr) and MSR[UM] = 1 and MSR[VM] = 1 then
←
ESR[EC]
←
MSR[UMS]
else
(rD)[24:31]
(rD)[0:23]
Registers Altered
• rD, unless an exception is generated, in which case the register is unchanged
• MSR[UM], MSR[VM], MSR[UMS], MSR[VMS], if an exception is generated
• ESR[EC], ESR[S], if an exception is generated
• ESR[DIZ], if a data storage exception is generated
MicroBlaze Processor Reference Guide
UG984 (v2016.2) June 8, 2016
UG984 (v2016.1) April 6, 2016
rD rA
11
←
10010;ESR[S] 0
← ←
MSR[UM]; MSR[VMS]
←
10000;ESR[S] 0; ESR[DIZ]
←
MSR[UM]; MSR[VMS]
←
Mem(Addr)
←
0
www.xilinx.com
Chapter 5: MicroBlaze Instruction Set Architecture
rB 0 R 0 EA 0 0 0 0 0 0 0
16 21
←
MSR[VM]; MSR[UM] 0; MSR[VM]
←
1
←
MSR[VM]; MSR[UM] 0; MSR[VM]
31
←
