After a MicroBlaze core has invalidated one or more entries, it must execute a memory
barrier instruction (MBAR), to ensure that all peer processors have completed their TLB
invalidation.
• Branch Target Cache invalidation:
When a MicroBlaze core in the coherency domain invalidates the Branch Target Cache,
either with a memory barrier instruction or with a synchronizing branch, hardware
messages ensure that all other cores in the coherency domain will do the same.
In particular, this means that self-modifying code can be used transparently within the
coherency domain in a multi-processor system, provided that the guidelines
modifying Code"
Protocol Compliance
The MicroBlaze instruction cache interface issues the following subset of the possible ACE
transactions:
• ReadClean
Issued when a cache line is allocated.
• ReadOnce
Issued when the cache is off, or if the MMU Inhibit Caching bit is set for the cache line.
The MicroBlaze data cache interface issues the following subset of the possible ACE
transactions:
• ReadClean
Issued when a cache line is allocated.
• CleanUnique
Issued when an SWX instruction is executed as part of an exclusive access sequence.
• ReadOnce
Issued when the cache is off, or if the MMU Inhibit Caching bit is set for the cache line.
• WriteUnique
Issued whenever a store instruction performs a write.
• CleanInvalid
Issued when a WDC.EXT.FLUSH instruction is executed.
• MakeInvalid
Issued when a WDC.EXT.CLEAR instruction is executed.
MicroBlaze Processor Reference Guide
UG984 (v2016.2) June 8, 2016
UG984 (v2016.1) April 6, 2016
are followed.
