Chapter 12: Guidelines and Examples
Table 12-1: Model-Derived Loss for Differential Vias of Various Dimensions (Continued)
Board Stub Via
Thickness Length Diameter
(mils) (mils) (mils)
16
0
12
16
125 28
12
16
95
12
10
0
8
10
50 11
8
10
39
8
To understand how to use
Example 1:
For a targeted BER at a data rate of 4.25 Gb/s, assume that an IL of less than 10 dB is
required. The channel is from a motherboard to a daughter card using a very clean
mezzanine connector with no appreciable loss. Assume a 100 mil thick motherboard and a
50 mil thick daughtercard with 0.4 dB/inch at 2.125 Ghz and 12-inch maximum routes for
4.8 dB of channel loss. Using the 125 mil long vias from the table, if no or short stubs are
allowed, then a 16 mil diameter/35 mil pitch via has –0.164 IL @ 2 GHz. Therefore, the via
pitch can simply be increased to 40 mils, and/or a 12 mil diameter via can be used to keep
the via IL below –0.1 dB. A –0.1 dB IL is presumed to be an acceptably low-loss for a
transition so as to have no noticeable effect on overall channel performance.
Example 2:
This example assumes a 6 Gb/s application and the choice of using either an expensive
connector with a 200 fF launch or a less expensive connector with a 400 fF launch. A board
260
Via Excess
RL @1GHz
Pitch Capac.
(dB)
(mils) (fF)
35 494 -22.2
50 33 -45.6
35 208 -29.7
50 163 -31.8
35 614 -20.3
50 177 -31.1
35 334 -25.6
50 12 -54.5
35 868 -17.3
50 392 -24.2
35 548 -21.3
50 265 -27.6
25 250 -28.1
35 67 -39.6
25 183 -30.8
35 22 -49.1
25 326 -25.8
35 131 -33.7
25 253 -28.0
35 67 -39.6
25 379 -24.5
35 201 -30.0
25 319 -26.0
35 158 -32.1
Table 12-1, three examples are given below:
