Displaying FICON Information
S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m .
Placing CUPs in a Zone
To place the CUP in a zone, follow these steps.
Step 1
Set the default zone to permit for the required VSAN.
switch# config t
switch(config)# zone default-zone permit vsan 20
Issue the show fcns database command for the required VSAN and obtain the required FICON CUP
Step 2
WWN.
switch# show fcns database vsan 20
VSAN 20:
--------------------------------------------------------------------------
FCID
--------------------------------------------------------------------------
0x0d0d00
0x0dfe00
0x200400
0x200800
0x20fe00
Total number of entries = 5
Note
Add the identified FICON:CUP WWN to the zone database.
Step 3
switch(config)# zone name Zone1 vsan 20
switch(config-zone)# member pwwn 25:00:00:0c:ce:5c:5e:c2
Displaying FICON Information
Use show commands to display all FICON information configured on a switch (see Examples
24-15).
Receiving FICON Alerts
In
Example 24-1
indicate any changes in the FICON configuration.
Cisco MDS 9000 Family Configuration Guide
24-28
TYPE
PWWN
N
50:06:04:88:00:1d:60:83 (EMC)
N
25:00:00:0c:ce:5c:5e:c2 (Cisco)
N
50:05:07:63:00:c2:82:d3 (IBM)
N
50:05:07:64:01:40:15:0f (IBM)
N
20:00:00:0c:30:ac:9e:82 (Cisco)
If more than one
FICON:CUP WWN
PWWNs to the required zone. The previous example displays multiple
to indicate a cascade configuration.
the
user alert mode is enabled
(VENDOR)
FC4-TYPE:FEATURE
FICON:CU
FICON:CUP
scsi-fcp FICON:CU f..
FICON:CH
FICON:CUP
exists in this fabric, be sure to add all the
output confirms that you will receive an alert to
OL-6973-03, Cisco MDS SAN-OS Release 2.x
Chapter 24
Configuring FICON
FICON:CUP WWN
occurrences
FICON:CUP
24-1
to
