Initial Setup Routine
S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m .
You see the new configuration. Review and edit the configuration that you have just entered.
Enter no (no is the default) if you are satisfied with the configuration.
Step 22
The following configuration will be applied:
username admin password admin_pass role network-admin
username user_name password user_pass role network-admin
snmp-server community snmp_community ro
switchname switch
interface mgmt0
ip routing
ip route dest_prefix dest_mask dest_address
ip default-network dest_prefix
ip default-gateway default_gateway
ip name-server name_server
ip domain-name domain_name
telnet server enable
ssh key dsa 768 force
ssh server enable
ntp server ipaddr ntp_server
system default switchport shutdown
system default switchport trunk mode on
system default port-channel auto-create
zone default-zone permit vsan 1-4093
zoneset distribute full vsan 1-4093
Would you like to edit the configuration? (yes/no) [n]: no
Enter yes (yes is default) to use and save this configuration:
Step 23
Use this configuration and save it? (yes/no) [y]: yes
Caution

Configuring In-Band Management

The in-band management logical interface is VSAN 1. This management interface uses the Fibre
Channel infrastructure to transport IP traffic. An interface for VSAN 1 is created on every switch in the
fabric. Each switch should have its VSAN 1 interface configured with an IP address in the same
subnetwork. A default route that points to the switch providing access to the IP network should be
configured on every switch in the Fibre Channel fabric (see
VSANs").
You can configure both in-band and out-of-band configuration together by entering Yes in both
Note
and
Cisco MDS 9000 Family Configuration Guide
4-10
ip address ip_address subnet_mask
no shutdown
If you do not save the configuration at this point, none of your changes are updated the next
time the switch is rebooted. Type yes in order to save the new configuration. This ensures that
the kickstart and system images are also automatically configured (see
Images").
Step 9d. in the following procedure.
Chapter 4 Initial Configuration
Chapter 6, "Software
Chapter 16, "Configuring and Managing
OL-6973-03, Cisco MDS SAN-OS Release 2.x
Step 9c.
