Configuring iSCSI
S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m .
Target Storage Device Requiring LUN Mapping
Sample scenario 2 assumes the following configuration (see
•
•
•
•
Figure 35-21 iSCSI Scenario 2
Host 1
iSCSI
iSCSI
Host 2
To configure scenario 2 (see
Configure null authentication for all iSCSI hosts.
Step 1
switch(config)# iscsi authentication none
Step 2
Configure iSCSI to dynamically import all Fibre Channel targets into the iSCSI SAN using
auto-generated iSCSI target names.
switch(config)# iscsi import target fc
Step 3
Configure the Gigabit Ethernet interface in slot 7 port 1 with an IP address and enable the interface.
switch(config)# int gigabitethernet 7/1
switch(config-if)# ip address 10.11.1.1 255.255.255.0
switch(config-if)# no shut
Configure the iSCSI interface in slot 7 port 1 to identify all dynamic iSCSI initiators by the IP address
Step 4
and enable the interface.
switch(config)# int iscsi 7/1
switch(config-if)# switchport initiator id ip-address
switch(config-if)# no shut
OL-6973-03, Cisco MDS SAN-OS Release 2.x
Access control is based on Fibre Channel zoning.
There is target-based LUN mapping or LUN masking.
There is no iSCSI authentication (none).
The iSCSI initiator is assigned to different VSANs.
VSAN 1
Switch 1
VSAN 2
Figure
iSCSI Authentication Setup Guidelines and Scenarios
Figure
Interface fc 2/1
21:00:00:20:37:6f:fd:97
Interface fc 2/5
iSCSI
21:00:00:20:37:6f:fe:54
Interface fc 2/9
21:00:00:20:37:a6:a6:5d
35-21), follow these steps:
