Configuring Broadcast Zoning

S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m .
Command
Step 4
switch(config)# zoneset name QosZoneset vsan 2
swtich(config-zoneset)#
Step 5
swtich(config-zoneset)# member QosZone
swtich(config-zoneset)# exit
switch(config)#
Step 6
switch(config)# zoneset activate name
QosZoneset vsan 2

Configuring Default Zone QoS Priority Attributes

QoS priority attribute configuration changes take effect when you activate the zone set of the associated
zone.
If a member is part of two zones with two different QoS priority attributes, the higher QoS value is
Note
implemented. This situation does not arise in the VSAN-based QoS as the first matching entry is
implemented.
To configure the QoS priority attributes for a default zone, follow these steps:
Command
Step 1
switch# config t
switch(config)#
Step 2
switch(config)# zone default-zone vsan 1
switch(config-default-zone)#
Step 3
switch123(config-zone)# attribute qos
priority high
switch123(config-zone)# no attribute qos
dscp
Configuring Broadcast Zoning
You can configure broadcast frames in the basic zoning mode. By default, broadcast zoning is disabled
and broadcast frames are sent to all Nx ports in the VSAN. When enabled, broadcast frames are only
sent to Nx ports in the same zone, or zones, as the sender. Enable broadcast zoning when a host or storage
device uses this feature.
If any NL port attached to an FL port shares a broadcast zone with the source of the broadcast frame,
Tip
then the frames are broadcast to all devices in the loop.
Cisco MDS 9000 Family Configuration Guide
19-16
Chapter 19 Configuring and Managing Zones
Purpose
Configures a zone set called QosZone set.
To activate a zone set, you must first
Tip
create the zone and a zone set.
Adds QosZone as a member of the specified
zone set (QosZoneset).
If the specified zone name was not
Tip
previously configured, this command
will return the
error message.
Activates the specified zone set.
Purpose
Enters configuration mode.
Enters the default-zone submode.
Sets the QoS priority attribute for frames matching
these zones.
Removes the QoS priority attribute for the default
zone and reverts to default low priority
OL-6973-03, Cisco MDS SAN-OS Release 2.x
Zone not present
