FSPF

Figure 33-11
two IP addresses on each SAN island, and addresses IP and FCIP link failures.
Figure 33-11 FSPF-Based Load Balancing
The following characteristics set FSPF solutions apart from other solutions:
•
•
•

VRRP

Figure 33-12
requires at least two physical Gigabit Ethernet ports connected to the Ethernet switch on the island where
you need to implement high availability using VRRP.
Figure 33-12 VRRP-Based High Availability
The following characteristics set VRRP solutions apart from other solutions:
•
•
•
OL-6973-03, Cisco MDS SAN-OS Release 2.x
displays a FPSF-based load balancing configuration example. This configuration requires
FC fabric
PortChannel of
two FCIP tunnels
Each FCIP link is a separate (E)ISL.
The FCIP links can connect to different switches across two SAN islands.
The Fibre Channel traffic is load balanced across the FCIP link.
displays a VRRP-based high availability FCIP configuration example. This configuration
FC fabric
IP interfaces are in VRRP group
If the active VRRP port fails, the standby VRRP port takes over the VRRP IP address.
When the VRRP switchover happens, the FCIP link automatically disconnects and reconnects.
This configuration has only one FCIP (E)ISL link.
FCIP link
IP
network
FCIP link
FCIP link
IP
network
