Configuring IVZs and IVZSs

S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m .
Configuring IVZs and IVZSs
This section describes how to configure IVZs and IVZSs.

Creating and Activating IVZs and IVZSs

When you activate an IVZS, IVR automatically adds an IVZ to the regular active zone set of each edge
VSAN. If a VSAN does not have an active zone set, IVR can only activate an IVZS using the force
option, which causes IVR to create an active zone set called "nozoneset" and adds the IVZ to that active
zone set.
Regular zone set activation and deactivation is per VSAN where IVR zone set activation and deactivation
Caution
is for a set of VSANs. If you deactivate the regular active zone set in a VSAN, the IVZs for the IVZS
are removed, and all IVR traffic to and from that VSAN is stopped. This occurs because the IVZs in the
regular active zone set of that VSAN are also removed and deactivated. IVR traffic between other
VSANs continues to function. To reactivate the IVZS, you must reactivate the regular zone set.
To replace the active IVR zone set with a new IVR zone set without disrupting traffic, activate the new
Note
IVR zone set without deactivating the current active IVR zone set.
To create and activate IVZs and IVZSs, follow these steps:
Command
Step 1
switch# config t
Step 2
switch(config)# ivr zone name sample_vsan2-3
switch(config-ivr-zone)#
Step 3
switch(config-ivr-zone)# member pwwn 21:00:00:e0:8b:02:ca:4a
vsan 3
Step 4
switch(config-ivr-zone)# member pwwn 21:00:00:20:37:c8:5c:6b
vsan 2
Step 5
switch(config-ivr-zone)# exit
switch(config)#
Step 6
switch(config)# ivr zone name sample_vsan4-5
switch(config-ivr-zone)#
Step 7
switch(config-ivr-zone)# member pwwn 21:00:00:e0:8b:06:d9:1d
vsan 4
Step 8
switch(config-ivr-zone)# member pwwn 21:01:00:e0:8b:2e:80:93
vsan 4
Step 9
switch(config-ivr-zone)# member pwwn 10:00:00:00:c9:2d:5a:dd
vsan 5
Step 10
switch(config-ivr-zone)# exit
switch(config)#
Step 11
switch(config)# ivr zoneset name Ivr_zoneset1
switch(config-ivr-zoneset)#
Cisco MDS 9000 Family Configuration Guide
18-22
Chapter 18 Configuring Inter-VSAN Routing
Purpose
Enters configuration mode.
Creates an IVR zone named
sample_vsan2-3.
Adds the specified pWWN in
VSAN 3 as an IVZ member.
Adds the specified pWWN in
VSAN 2 as an IVZ member.
Reverts to configuration mode.
Creates an IVZ named
sample_vsan4-5.
Adds the specified pWWN in
VSAN 4 as an IVZ member.
Adds the specified pWWN in
VSAN 4 as an IVZ member.
Adds the specified pWWN in
VSAN 5 as an IVZ member.
Reverts to configuration mode.
Creates an IVZS named
Ivr_zoneset1.
OL-6973-03, Cisco MDS SAN-OS Release 2.x
