Fibre Channel Interfaces
S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m .

Identifying the Beacon LEDs

Figure 11-3
Figure 11-3
1
2
1. See the
2. See the
3. See the
4. Refer to the Cisco MDS 9000 Family Hardware Installation Guide.

About Speed LEDs

Each port has one link LED on the left and one speed LED on the right.
The speed LED displays the speed of the port interface:
•
•
The speed LED also displays if the beacon mode is enabled or disabled:
•
•

Bit Error Thresholds

The bit error rate threshold is used by the switch to detect an increased error rate before performance
degradation seriously affects traffic.
The bit errors can occur for the following reasons:
•
•
•
•
•
•
Cisco MDS 9000 Family Configuration Guide
11-18
displays the status, link, and speed LEDs in a 16-port switching module.
Cisco MDS 9000 Family Switch Interface Modes
1 3
1
Status LED
1/2-Gbps Fibre Channel port group
"Identifying Module LEDs" section on page
"About Speed LEDs" section on page
"32-Port Configuration Guidelines" section on page
Off—The interface attached to that port is functioning at 1000 Mbps.
On (solid green)—The interface attached to that port is functioning at 2000 Mbps (for 2 Gbps
interfaces).
Off—Beacon mode is disabled.
On (flashing green)—The beacon mode is enabled. The LED flashes at one-second intervals.
Faulty or bad cable
Faulty or bad GBIC or SFP
GBIC or SFP is specified to operate at 1 Gbps but is used at 2 Gbps
GBIC or SFP is specified to operate at 2 Gbps but is used at 4 Gbps
Short haul cable is used for long haul or long haul cable is used for short haul
Momentary sync loss
2
1
3 Link LEDs and speed LEDs
3 4
4 Asset tag
10-11.
11-18.
11-8.
Chapter 11 Configuring Interfaces
4
2
OL-6973-03, Cisco MDS SAN-OS Release 2.x
