Configuring IP Services
Cisco MDS 9000 Family switches can route IP traffic between Ethernet and Fibre Channel interfaces.
The IP static routing feature is used to route traffic between VSANs. To do so, each VSAN must be in a
different IP subnetwork. Each Cisco MDS 9000 Family switch provides the following services for
network management systems (NMS):
IP forwarding on the out-of-band Ethernet interface (mgmt0) on the front panel of the supervisor
•
modules.
IP forwarding or in-band Fibre Channel interface using the IP over Fibre Channel (IPFC)
•
function—IPFC specifies how IP frames can be transported over Fibre Channel using encapsulation
techniques. IP frames are encapsulated into Fibre Channel frames so NMS information can cross the
Fibre Channel network without using an overlay Ethernet network.
IP routing (default routing and static routing)—If your configuration does not need an external
•
router, you can configure a default route using static routing.
Switches are compliant with RFC 2338 standards for Virtual Router Redundancy Protocol (VRRP)
features. VRRP is a restartable application that provides a redundant, alternate path to the gateway
switch.
This chapter includes the following sections:
Traffic Management Services, page 36-2
•
• Management Interface Configuration, page 36-2
Default Gateway Configuration, page 36-3
•
• Default Network Configuration, page 36-4
IPFC Configuration, page 36-5
•
Configuring IP Static Routes, page 36-10
•
Displaying IP Interface Information, page 36-11
•
Overlay VSAN Configuration, page 36-12
•
Multiple VSAN Configuration, page 36-14
•
The Virtual Router Redundancy Protocol, page 36-16
•
DNS Server Configuration, page 36-23
•
Default Settings, page 36-24
•
