Chapter 34 Configuring the SAN Extension Tuner
S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m .

nWWN Configuration

To configure the nWWNs for the tuner in this switch, follow these steps:
Command
Step 1
switch# san-ext-tuner
switch(san-ext)#
Step 2
switch(san-ext)# nWWN 10:00:00:00:00:00:00:00

Virtual N Port Configuration

To configure the virtual N port for tuning, follow these steps:
Command
Step 1
switch# config t
switch(config)#
Step 2
switch(config)# iscsi enable
Step 3
switch(config)# interface iscsi 3/4
switch(config-if)#
Step 4
switch(config-if)# no shutdown
Step 5
switch(config-if)# end
switch#
Step 6
switch# san-ext-tuner
switch(san-ext)#
Step 7
switch(san-ext)# nWWN 10:00:00:00:00:00:00:00
Step 8
switch(san-ext)# nport pWWN
12:00:00:00:00:00:00:56 vsan 200 interface
gigabitethernet 3/4
switch(san-ext-nport)#
switch(san-ext)# no nport pWWN
22:34:56:78:90:12:34:56 vsan 200 interface
gigabitethernet 3/4

SCSI Read/Write Assignment

You can assign SCSI read and write commands on a one-time basis or on a continuous basis.
To assign SCSI read and (or) write commands on a one-time basis, follow these steps:
Command
Step 1
switch# san-ext-tuner
switch(san-ext)#
Step 2
switch(san-ext)# nWWN 10:00:00:00:00:00:00:00
OL-6973-03, Cisco MDS SAN-OS Release 2.x
Purpose
Enters the SET configuration submode.
Configures the nWWN for the SAN
extension tuner.
Purpose
Enters configuration mode.
Enables iSCSI.
Creates an iSCSI interface and enters
interface configuration submode.
Enables the iSCSI interface.
Returns to EXEC mode.
Enters the SET configuration submode.
Configures the nWWN for the SAN
extension tuner.
Creates a virtual N port on the specified
Gigabit Ethernet port and VSAN. This N port
can act as a initiator or a target.
Removes a virtual N port on the specified
Gigabit Ethernet port and VSAN.
Purpose
Enters the SET configuration submode.
Configures the nWWN for the SAN
extension tuner.
Cisco MDS 9000 Family Configuration Guide
nWWN Configuration
34-5
