Chapter 19 Configuring and Managing Zones
S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m .
If broadcast zoning is enabled on a switch, you cannot configure the interop mode in that VSAN.
Caution
To broadcast frames in the basic zoning mode, follow these steps:
Command
Step 1
switch# config t
switch(config)#
Step 2
switch(config)# zone broadcast enable vsan 2
switch(config)# no zone broadcast enable vsan 3
Step 3
switch(config)# zone name BcastZone vsan 2
switch(config-zone)#
Step 4
switch(config-zone)# member pwwn
21:00:00:20:37:f0:2e:4d
Step 5
switch(config-zone)# attribute broadcast
Step 6
switch(config-zone)# end
switch# show zone vsan 2
zone name bcast-zone vsan 2
attribute broadcast
pwwn 21:00:00:e0:8b:0b:66:56
pwwn 21:00:00:20:37:f0:2e:4d

About LUN Zoning

Logical unit number (LUN) zoning is a feature specific to switches in the Cisco MDS 9000 Family.
LUN zoning can only be implemented in Cisco MDS 9000 Family switches. If LUN zoning is
Caution
implemented in a switch, you cannot configure the interop mode in that switch.
A storage device can have multiple LUNs behind it. If the device port is part of a zone, a member of the
zone can access any LUN in the device. With LUN zoning, you can restrict access to specific LUNs
associated with a device.
When LUN 0 is not included within a zone, then, as per standards requirements, control traffic to LUN
Note
0 (for example, REPORT_LUNS, INQUIRY) is supported, but data traffic to LUN 0 (for example,
READ, WRITE) is denied.
•
•
Unzoned LUNs automatically become members of the default zone.
Note
Figure 19-6
OL-6973-03, Cisco MDS SAN-OS Release 2.x
Host H1 can access LUN 2 in S1 and LUN 0 in S2. It cannot access any other LUNs in S1 or S2.
Host H2 can access LUNs 1 and 3 in S1 and only LUN 1 in S2. It cannot access any other LUNs in
S1 or S2.
shows a LUN-based zone example.
Purpose
Enters configuration mode.
Broadcasts frames for the specified VSAN.
Disables (default) broadcasting for the
specified VSAN.
Creates a broadcast zone in the specified
VSAN.
Adds the specified member to this zone.
Specifies this zone to be broadcast to other
devices.
Displays the broadcast configuration
Cisco MDS 9000 Family Configuration Guide
About LUN Zoning
19-17
