Configuring Modem Connections
S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m .

Configuring the Default Initialization String

To configure the default initialization string through the COM1 port, follow these steps:
Command
Step 1
switch# config t
switch(config)#
Step 2
switch(config)# line com1
switch(config-com1)#
Step 3
switch(config-com1)# modem init-string
default
To configure the default initialization string through the console port, follow these steps:
Command
Step 1
switch# config t
switch(config)#
Step 2
switch(config)# line com1
switch(config-console)#
Step 3
switch(config-console)# modem
init-string default

Configuring a User-Specified Initialization String

To configure a user-specified initialization string through the COM1 port, follow these steps:
Command
Step 1
switch# config terminal
switch(config)#
Step 2
switch(config)# line com1
switch(config-com1)#
Step 3
switch(config-com1)# modem set-string
user-input ATE0Q1&D2&C1S0=3\015
switch(config-com1)# no modem set-string
Step 4
switch(config-com1)# modem init-string
user-input
To configure a user-specified initialization string through the console port, follow these steps:
Command
Step 1
switch# config terminal
switch(config)#
Step 2
switch(config)# line com1
switch(config-console)#
Cisco MDS 9000 Family Configuration Guide
4-30
Command
Enters configuration mode.
Enters the COM1 port configuration mode.
Writes the default initialization string to the modem.
Command
Enters configuration mode.
Enters the console port configuration mode.
Writes the default initialization string to the modem.
Command
Enters configuration mode.
Enters the COM1 port configuration mode.
Assigns the user-specified initialization string to its
corresponding profile.
You must first set the user-input string, before
Note
initializing the string.
Reverts the configured initialization string to the
factory default string.
Writes the user-specified initialization string to the
modem.
Command
Enters configuration mode.
Enters the console port configuration mode.
OL-6973-03, Cisco MDS SAN-OS Release 2.x
Chapter 4 Initial Configuration
