Chapter 10 Managing Modules
S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m .
Table 10-7
Table 10-7
LED
Status
Speed
Link
1. The Generation-2 switching modules (4-Gbps and 10-Gbps) do not have speed LEDs.
OL-6973-03, Cisco MDS SAN-OS Release 2.x
describes the LEDs for the Fibre Channel switch modules:
LEDs for the Cisco MDS 9000 Family Fibre Channel Switching Modules
Status Description
Green All diagnostics pass. The module is operational (normal initialization
sequence).
Orange The module is booting or running diagnostics (normal initialization sequence).
or
The inlet air temperature of the system has exceeded the maximum system
operating temperature limit (a minor environmental warning). To ensure
maximum product life, you should immediately correct the environmental
temperature and restore the system to normal operation.
Red The diagnostic test failed. The module is not operational because a fault
occurred during the initialization sequence.
or
he inlet air temperature of the system has exceeded the safe operating
T
temperature limits of the card (a major environmental warning). The card has
been shut down to prevent permanent damage.
1
On 2-Gbps mode.
Off 1-Gbps mode.
Solid green Link is up.
Steady Link is up (beacon used to identify port).
flashing
green
Intermittent Link is up (traffic on port).
flashing
green
Solid Link is disabled by software.
yellow
Flashing A fault condition exists.
yellow
Off No link.
Identifying Module LEDs
Cisco MDS 9000 Family Configuration Guide
10-13
