Chapter 16 Configuring and Managing VSANs
S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m .
Trunking ports have an associated list of VSANs that are part of an allowed list (see
"Configuring

Creating and Configuring VSANs Statically

You cannot configure any application-specific parameters for a VSAN before creating the VSAN.
To create and configure VSANs, follow these steps:
Command
Step 1
switch# config t
Step 2
switch(config)# vsan database
switch(config-vsan-db)#
Step 3
switch(config-vsan-db)# vsan 2
switch(config-vsan-db)#
switch(config-vsan-db)# vsan 2 name TechDoc
updated vsan 2
switch(config-vsan-db)#
Step 4
switch(config-vsan-db)# vsan 2
loadbalancing src-dst-id
switch(config-vsan-db)#
switch(config-vsan-db)# no vsan 2
loadbalancing src-dst-id
switch(config-vsan-db)#
switch(config-vsan-db)# vsan 2
loadbalancing src-dst-ox-id
switch(config-vsan-db)#
Step 5
switch(config-vsan-db)# vsan 2 suspend
switch(config-vsan-db)#
switch(config-vsan-db)# no vsan 2 suspend
vs.-config-vsan-db#
Step 6
switch(config-vsan-db)# end
switch#

Assigning Static Port VSAN Membership

To statically assign VSAN membership for an interface, follow these steps:
Command
Step 1
switch# config t
Step 2
switch(config)# vsan database
switch(config-vsan-db)#
Step 3
switch(config-vsan-db)# vsan 2
switch(config-vsan-db)#
OL-6973-03, Cisco MDS SAN-OS Release 2.x
See Chapter 17, "Creating Dynamic
Trunking").
Creating and Configuring VSANs Statically
VSANs.".
Purpose
Enters configuration mode.
Configures the database for a VSAN. Application
specific VSAN parameters cannot be configured
from this prompt.
Creates a VSAN with the specified ID (2) if that
VSAN does not exist already.
Updates the VSAN with the assigned name
(TechDoc).
Enables the load balancing guarantee for the
selected VSAN and directs the switch to use the
source and destination ID for its path selection
process.
Negates the command issued in the previous step
and reverts to the default values of the
load-balancing parameters.
Changes the path selection setting to use the source
ID, the destination ID, and the OX ID (default).
Suspends the selected VSAN.
Negates the suspend command issued in the
previous step.
Returns you to EXEC mode.
Purpose
Enters configuration mode.
Configures the database for a VSAN.
Creates a VSAN with the specified ID (2) if
that VSAN does not exist already.
Cisco MDS 9000 Family Configuration Guide
Chapter 12,
16-7
