Configuring IVR Topologies
S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m .
Migrating from IVR Topology Automatic Mode to Manual Mode
If you want to migrate the active IVR VSAN topology database from automatic mode to user-configured
mode, first copy the active IVR VSAN topology database to the user-configured IVR VSAN topology
database before switching modes. To migrate from automatic mode to manual mode, follow these steps:
Command
Step 1
switch# ivr copy auto-topology
user-configured-topology
Step 2
switch# config t
switch(config)#
Step 3
switch(config)# ivr vsan-topology active
Clearing the Configured IVR Topology Database
To clear the user-configured IVR VSAN topology database using, follow these steps:
Command
Step 1
switch# config t
switch(config)#
Step 2
switch(config)# no ivr vsan-topology database

Verifying the IVR Topology

You can verify the IVR topology by using the show ivr vsan-topology command. See
Example
Example 18-1 Displays the Configured IVR VSAN Topology
switch# show ivr vsan-topology
AFID
--------------------------------------------------------------
1
1
1
Total:
Current Status: Inter-VSAN topology is ACTIVE
Last activation time: Sat Mar 22 21:46:15 1980
The asterisk (*) indicates the local switch.
Cisco MDS 9000 Family Configuration Guide
18-14
18-3.
SWITCH WWN
20:00:00:05:30:01:1b:c2 *
20:02:00:44:22:00:4a:05
20:02:00:44:22:00:4a:07
5 entries in active and configured IVR VSAN-Topology
Chapter 18
Purpose
Copies the automatic IVR topology database to
the user-configured IVR topology.
Enters configuration mode.
Disabled automatic mode for the IVR topology
database and enables user-configuration mode.
Purpose
Enters configuration mode.
Clears the previously created IVR topology.
Active Cfg. VSANS
yes yes 1-2
yes yes 1-2,6
yes yes 2-5
Configuring Inter-VSAN Routing
Example 18-1
OL-6973-03, Cisco MDS SAN-OS Release 2.x
to
