Analog Devices ADV7850 Hardware Manual page 58

Function
tri1_readback[1:0]
1x
0x
x1
x0
tri2_readback[1:0], AFE, Address 0x27[5:4] (Read Only)
This readback displays Tri2 DC levels.
Function
tri2_readback[1:0]
1x
0x
x1
x0
tri3_readback[1:0], AFE, Address 0x27[3:2] (Read Only)
This readback displays Tri3 DC levels.
Function
tri3_readback[1:0]
1x
0x
x1
x0
tri4_readback[1:0], AFE, Address 0x27[1:0] (Read Only)
This readback displays Tri4 DC levels.
Function
tri4_readback[1:0]
1x
0x
x1
x0
tri5_readback[1:0], AFE, Address 0x28[7:6] (Read Only)
This readback displays Tri5 DC levels.
Function
tri5_readback[1:0]
1x
0x
x1
x0
tri6_readback[1:0], AFE, Address 0x28[5:4] (Read Only)
This readback displays Tri6 DC levels.
Rev. A May 2012
Description
Signal higher than upper level
Signal lower than upper level
Signal higher than lower level
Signal lower than lower level
Description
Signal higher than upper level
Signal lower than upper level
Signal higher than lower level
Signal lower than lower level
Description
Signal higher than upper level
Signal lower than upper level
Signal higher than lower level
Signal lower than lower level
Description
Signal higher than upper level
Signal lower than upper level
Signal higher than lower level
Signal lower than lower level
Description
Signal higher than upper level
Signal lower than upper level
Signal higher than lower level
Signal lower than lower level
