Analog Devices ADV7850 Hardware Manual page 37

prim_mode[3:0]
Code Description
e.g. CVBS
COMP
0001 (Component Video)
e.g. YPrPb
Rev. A May 2012
Processor Code
00011
00100
00101
00110
00111
01000
01001
01010
01011
01100
01101
01110
01111
11111
10000
10001
10010
10011
10100
10101
10110
10111
11000
11001
11010
11110
11111
000000
000001
000010
000011
000100
000101
000110
000111
CP 001000
001001
001010
001011
001100
001101
001110
001111
010000
010001
010010
010011
010100
010101
vid_std[5:0]
Input Video Output Resolution
Reserved Reserved
SD 2x1 720x480i/576i
SD 4x1 720x480i/576i
Reserved Reserved
Reserved Reserved
SD 2x1 720x480i/576i
SD 4x1 720x480i/576i
SD 8x1 720x480i/576i
Reserved Reserved
SD 2x1 720x480i/576i
SD 4x1 720x480i/576i
Reserved Reserved
Reserved Reserved
Reserved Reserved
SD 2X1 YPrPb 720X480i/576i
SD 4X1 YPrPb 720X480i/576i
Reserved Reserved
Reserved Reserved
Reserved Reserved
Reserved Reserved
Reserved Reserved
Reserved Reserved
SD 2x1 RGB 720x480i/576i
SD 4x1 RGB 720x480i/576i
Reserved Reserved
Reserved Reserved
Reserved Reserved
Reserved Reserved
Reserved Reserved
SD 2x1 525i 720 x 480i
SD 2x1 625i 720 x 576i
SD 4x1 525i 720 x 480i
SD 4x1 625i 720 x 576i
SD 2x2 525i 1440 x 480i
SD 2x2 625i 1440 x 576i
SD 4x2 525i 1440 x 480i
SD 4x2 625i 1440 x 576i
Reserved Reserved
Reserved Reserved
PR 2x1 525p 720 x 480p
PR 2x1 625p 720 x 576p
PR 4x1 525p 720 x 480p
PR 4x1 625p 720 x 576p
PR 2x2 525p 1440 x 480p
PR 2x2 625p 1440 x 576p
Reserved Reserved
HD 1x1 720p 1280 x 720p
HD 1x1 1125 1920 x 1080i
HD 1x1 1125 1920 x 1035i
37
ADV7850
Comment
SCART RGB
SCART RGB
YC
YC
YC
YC auto
YC auto
SD Component
SD Component
SD Component
SD Component
SMPTE 296M
SMPTE 274M
SMPTE 240M
