Analog Devices ADV7850 Hardware Manual page 133

Function
sdp_csc_auto
0
1 <<
sdp_csc_scale, Addr 94 (sdp_IO), Address 0xE0[7]
This control is used to set the CSC gain.
Function
sdp_csc_scale
0 <<
1
This bit allows the control to accommodate coefficients that extend the supported range of the DPP.
sdp_a1[12:0], Addr 94 (sdp_IO), Address 0xE0[4:0]; Address 0xE1[7:0]
This control is used to set the CSC A1 coefficient for the SDP output color space converter.
Function
sdp_a1[12:0]
0x07D2 <<
sdp_a2[12:0], Addr 94 (sdp_IO), Address 0xE2[4:0]; Address 0xE3[7:0]
This control is used to set the CSC A2 coefficient for the SDP output color space converter.
Function
sdp_a2[12:0]
0x0000 <<
sdp_a3[12:0], Addr 94 (sdp_IO), Address 0xE4[4:0]; Address 0xE5[7:0]
This control is used to set the CSC A3 coefficient for the SDP output color space converter.
Function
sdp_a3[12:0]
0x0040 <<
sdp_a4[14:0], Addr 94 (sdp_IO), Address 0xE6[6:0]; Address 0xE7[7:0]
This control is used to set the CSC A4 coefficient for the SDP output color space converter.
Function
sdp_a4[14:0]
0x7F00 <<
sdp_b1[12:0], Addr 94 (sdp_IO), Address 0xE8[4:0]; Address 0xE9[7:0]
This control is used to set the CSC B1 coefficient for the SDP output color space converter.
Rev. A May 2012
Description
Use manual CSC coefficients
Use automatic CSC coefficients
Description
CSC scaler set to 1
CSC scaler set to 2
Description
Default
Description
Default
Description
Default
Description
Default
133
ADV7850
