Analog Devices ADV7850 Hardware Manual page 134

Function
sdp_b1[12:0]
0x0000 <<
sdp_b2[12:0], Addr 94 (sdp_IO), Address 0xEA[4:0]; Address 0xEB[7:0]
This control is used to set the CSC B2 coefficient for the SDP output color space converter.
Function
sdp_b2[12:0]
0x0926 <<
sdp_b3[12:0], Addr 94 (sdp_IO), Address 0xEC[4:0]; Address 0xED[7:0]
This control is used to set the CSC B3 coefficient for the SDP output color space converter.
Function
sdp_b3[12:0]
0x0000 <<
sdp_b4[14:0], Addr 94 (sdp_IO), Address 0xEE[6:0]; Address 0xEF[7:0]
This control is used to set the CSC B4 coefficient for the SDP output color space converter.
Function
sdp_b4[14:0]
0x0000 <<
sdp_c1[12:0], Addr 94 (sdp_IO), Address 0xF0[4:0]; Address 0xF1[7:0]
This control is used to set the CSC C1 coefficient for the SDP output color space converter.
Function
sdp_c1[12:0]
0x0000 <<
sdp_c2[12:0], Addr 94 (sdp_IO), Address 0xF2[4:0]; Address 0xF3[7:0]
This control is used to set the CSC C2 coefficient for the SDP output color space converter.
Function
sdp_c2[12:0]
0x0000 <<
sdp_c3[12:0], Addr 94 (sdp_IO), Address 0xF4[4:0]; Address 0xF5[7:0]
This control is used to set the CSC C3 coefficient for the SDP output color space converter.
Function
sdp_c3[12:0]
0x0681 <<
sdp_c4[14:0], Addr 94 (sdp_IO), Address 0xF6[6:0]; Address 0xF7[7:0]
This control is used to set the CSC C4 coefficient for the SDP output color space converter.
Rev. A May 2012
Description
Default
Description
Default
Description
Default
Description
Default
Description
Default
Description
Default
Description
Default
134
ADV7850
