Table 36: Hdmi Flags In Io Map Register 0X60; Table 37: Hdmi Flags In Io Map Register 0X65; Table 38: Hdmi Flags In Io Map Register 0X6A; Table 39: Hdmi Flags In Io Map Register 0X6F - Analog Devices ADV7850 Hardware Manual

Bit Name Bit
Position
avi_info_raw 0 (LSB)
audio_info_raw 1
spd_info_raw 2
ms_info_raw 3
vs_info_raw 4
acp_pckt_raw 5
isrc1_pckt_raw 6
isrc2_pckt_raw 7 (MSB)
Bit Name Bit
Position
gamut_mdata_raw 0 (LSB)
audio_c_pckt_raw 1
gen_ctl_pckt_raw 2
hdmi_mode_raw 3
audio_ch_md_raw 4
av_mute_raw 5
internal_mute_raw 6
cs_data_valid_raw 7 (MSB)
Rev. A May 2012

Table 36: HDMI Flags in IO Map Register 0x60

Description
Returns 1 if AVI InfoFrame received within last seven VSyncs.
Returns 1 if AVI InfoFrame received within last three VSync. Additional description available on page 203.
Returns 1 if SPD InfoFrame received. Additional description available on page
Returns 1 if MPEG InfoFrame received within last three VSync. Additional description available on page
205.
Returns 1 if Vendor Specific InfoFrame received. Additional description available on page
Returns 1 if ACP packet received within last 600 ms. Additional description available on page
Returns 1 if ISRC1 packet received. Additional description available on page 209.
Returns 1 if ISRC2 packet received. Additional description available on page

Table 37: HDMI Flags in IO Map Register 0x65

Description
Returns 1 if Gamut Metadata packet received. Additional description available on page 210.
Returns 1 if audio clock regeneration packet received. Reset to 0 following a packet detection flag reset
condition. (Refer to Section 7.43.)
Returns 1 if general control packet received. Reset to 0 following a packet detection flag reset condition.
(Refer to Section 7.43.)
Returns 1 if a HDMI stream is being received. Additional description available on page
Returns 1 if audio channel mode is multi-channel (2, 4, 6 or 8 channel) audio. Reset to 0 following a
packet detection flag reset condition. (Refer to Section 7.43.) Additional description available on page
191.
Returns 1 if latest general control packet received has av_mute asserted. Reset to 0 following a packet
detection flag reset condition. (Refer to Section 7.43.)
Returns 1 if ADV7850 has internally muted the audio data. Additional information available on page 194.
Returns 1 if channel status bit readback registers in HDMI Map, Address 0x36 to 0x3A are
Additional information available on page 196.

Table 38: HDMI Flags in IO Map Register 0x6A

Bit Name
tmds_clk_d_raw
tmds_clk_c_raw
tmds_clk_b_raw
tmds_clk_a_raw
tmdspll_lck_d_raw
tmdspll_lck_c_raw
tmdspll_lck_b_raw
tmdspll_lck_a_raw

Table 39: HDMI Flags in IO Map Register 0x6F

Bit Name
cable_det_d_raw
cable_det_c_raw
cable_det_b_raw
cable_det_a_raw
hdmi_encrpt_d_raw
hdmi_encrpt_c_raw
hdmi_encrpt_b_raw
hdmi_encrpt_a_raw

Table 40: HDMI Flags in IO Map Register 0x74

Bit Name
de_regen_lck_raw
v_locked_raw
video_3d_raw
Bit Position Description
0 (LSB) Description available on page
1 Description available on page
2 Description available on page
3 Description available on page
4 Description available on page
5 Description available on page
6 Description available on page
7 (MSB) Description available on page
Bit Position Description
0 (LSB) Description available on page
1 Description available on page
2 Description available on page
3 Description available on page
4 Description available on page
5 Description available on page
6 Description available on page
7 (MSB) Description available on page
Bit Position Description
0 (LSB) Description available on page
1 Description available on page
2 3D Video Detected RAW status bit
223
ADV7850
204.
206.
208.
210.
153.
valid.
154
154
154
153
157
157
157
157
137
137
137
137
166
166
166
166
170
