Analog Devices ADV7850 Hardware Manual page 445

Location Mnemonic
M4 SCL
M7 VDD
M8 GND
M9 GND
M10 GND
M11 GND
M12 GND
M13 GND
M14 GND
M15 GND
M16 GND
M17 GND
M20 AC_AVDD
M21 GND
M22 GND
M23 GND
N1 HA_AP2
N2 HA_AP1
N3 AC_MCLK
N4 AC_LRCLK
N7 VDD
N8 GND
N9 GND
N10 GND
N11 GND
N12 GND
N13 GND
N14 GND
N15 GND
N16 GND
N17 GND
N20 PVDD
N21 PVDD
N22 XTALN
N23 XTALP
P1 HA_AP0
P2 HA_MCLKOUT
P3 AC_SDI
P4 AC_SCLK
P7 VDD
P8 GND
P9 GND
P10 GND
P11 GND
P12 GND
P13 GND
P14 GND
P15 GND
P16 GND
P17 GND
P20 GND
Rev. A May 2012
Type Recommended Configuration if Not Used
Miscellaneous digital This pin is always connected to the I2C clock line of a control
processor
Power This pin is always connected to Digital core supply voltage (1.8 V)
Ground Ground
Ground Ground
Ground Ground
Ground Ground
Ground Ground
Ground Ground
Ground Ground
Ground Ground
Ground Ground
Ground Ground
Audio block supply
(3.3V)
Ground Ground
Ground Ground
Ground Ground
HDMI Output Float this pin
HDMI Output Float this pin
Miscellaneous digital This pin should be connected to an oscillator or MCLK source when
using audio codec.
If Audio Codec is not in use, Float this pin
Miscellaneous digital Float this pin
Power This pin is always connected to Digital core supply voltage (1.8 V)
Ground Ground
Ground Ground
Ground Ground
Ground Ground
Ground Ground
Ground Ground
Ground Ground
Ground Ground
Ground Ground
Ground Ground
Power This pin is always connected to PLL supply voltage (1.8 V)
Power This pin is always connected to PLL supply voltage (1.8 V)
Miscellaneous analog This pin is always connected to 27MHz crystal
Miscellaneous analog This pin is always connected to 27MHz crystal or external clock
HDMI Output Float this pin
HDMI Output Float this pin
Miscellaneous digital Float this pin
Miscellaneous digital Float this pin
Supply This pin is always connected to Digital core supply voltage (1.8 V)
Ground Ground
Ground Ground
Ground Ground
Ground Ground
Ground Ground
Ground Ground
Ground Ground
Ground Ground
Ground Ground
Ground Ground
Ground Ground
445
ADV7850
