18 APPENDIX C
18.1

PACKAGE OUTLINE DRAWING

A1 BALL
CORNER
18.2

ORDERING GUIDE

Model
ADV7850KBCZ-5
1, 2, 3
EVAL-ADV7850EB1Z
1, 3, 4, 5
1 Z = RoHS Compliant Part.
2 Speed grade: 5 = 170 MHz.
This part is programmed with internal HDCP keys. Customers must have HDCP adopter status (consult Digital Content Protection, LLC, for licensing requirements) to
3
purchase any components with internal HDCP keys.
An ATV motherboard is also required to process the ADV7850 digital outputs and achieve video output. An ATV video output board is optional to evaluate performance
4
through an HDMI transmitter and video encoder.
Front-end board for the ATV video evaluation platform, fitted with ADV7850KBCZ-5 decoder.
5
Note: The ADV7850 is a Pb-free environmentally friendly product. It is manufactured using the most up-to-date materials and processes.
The coating on the leads of each device is pure Sn electroplate. The device is suitable for Pb-free applications and is able to withstand
surface-mount soldering at up to 255°C (±5°C). In addition, it is backward compatible with conventional SnPb soldering processes. This
means that the electroplated Sn coating can be soldered with SnPb solder pastes at conventional reflow temperatures of 220°C to 235°C.
Rev. A May 2012
19.20
19.00 SQ
18.80
TOP VIEW
DETAIL A
1.50
1.36
1.21
* COMPLIANT TO JEDEC STANDARDS MO-205 WITH THE EXCEPTION
TO PACKAGE BALL THICKNESS.
Figure 161 425-Ball Chip Scale Package Ball Grid Array [CSP_BGA]
Dimensions shown in millimeters
Temperature Range
0°C to +70°C
0°C to +70°C
22 20 18
23 21 19
17.60
BSC SQ
0.80
BSC
0.65
DETAIL A
NOM
0.35
NOM
SEATING
PLANE
(BC-425-1)
Package Description
425-Ball Chip Scale Package Ball Grid Array [CSP_BGA]
Front-End Evaluation Board
440
16 14 12 10 8 6 4 2
17 15 13 11 9 7 5 3 1
A
B
C
D
E
F
G
H
J
K
L
M
N
P
R
T
U
V
W
Y
AA
AB
AC
BOTTOM VIEW
1.11
1.01
0.91
0.35 NOM
0.30 MIN
* 0.50
COPLANARITY
0.45 0.20
0.40
BALL DIAMETER
ADV7850
Package Option
BC-425-1
